• Weatherproof Batten

Viking LED IP65

Weatherproof Batten

The Famco Viking LED series of premium weatherproof, adverse environment luminaires for use in high humidity, dampness, dust and/or corrosive locations.

LED LAMP:

  • Dedicated LED engine for maximum spacings
  • Two lumen packages:       2100lm or 4100lm
  • Nominal Colour Temp:    4000K
  • Rated Average Life:       50000 Hours

CONSTRUCTION:

  • Polyester compression moulded body, glass reinforced (GRP)
  • Built in gasket
  • IP65 rated
  • Grommets supplied for cable entry at both ends.
  • Stainless steel toggle clips 316 grade
  • Clear reeded polycarbonate lens
  • Supplied with electronic drivers
  • Complies with AS/NZS 60598.1 and CISPR15:2006

OPTIONS:

  • Dali
  • Daylight & Microwave Motions Sensor
  • Vandal Resistant Clips
  • Emergency versions compatible with
    MasterMinder system

APPLICATIONS:

Wherever a cost effective dust & water resistant fitting is required.

  • Carparks
  • Stairwells
  • Food premises
  • Chemical plants
  • Railway areas
  • Security areas
  • Factories
  • Hose down areas
PRODUCTDESCRIPTIONPHOTOMETRICS
Mains
FL980152 – foot mains
FL98015D2 – foot mains DALI
FL98015Q2 – foot mains with on/off sensor
FL98015QU2 – foot mains with dimmable sensor
FL980164 – foot mains
FL98016D4 – foot mains DALI
FL98016Q4 – foot mains with on/off sensor
FL98016QU4 – foot mains with dimmable sensor
Standalone emergency – Switched Maintained
FL99015/LI2 – foot lithium
FL99015D/LI2 – foot lithium DALI
FL99015Q/LI2 – foot lithium with on/off sensor
FL99015QU/LI2 – foot lithium with dimmable sensor
FL99016/LI4 – foot lithium
FL99016D/LI4 – foot lithium DALI
FL99016Q/LI4 – foot lithium with on/off sensor
FL99016QU/LI4 – foot lithium with dimmable sensor
Masterminder emergency – Switched Maintained
FLX99015/LI2 – foot lithium
FLX99015D/LI2 – foot lithium DALI
FLX99015Q/LI2 – foot lithium with on/off sensor
FLX99015QU/LI2 – foot lithium with dimmable sensor
FLX99016/LI4 – foot lithium
FLX99016D/LI4 – foot lithium DALI
FLX99016Q/LI4 – foot lithium with on/off sensor
FLX99016QU/LI4 – foot lithium with dimmable sensor
DALI emergency – Switched Maintained
FL99015/D2 – foot NiMh
FL99016/D4 – foot NiMh
